EBL 31-3 31-2

ELECTROBLOCKS | MOTORCARAVAN

The EBL 31‑2 Electroblock Motorcaravan is a power management system designed to generate charging voltages and distribute energy across onboard batteries while protecting output circuits. Read more

Find a Dealer

Quick fact

Devices for generating charging voltages for all batteries installed in the motorcaravan (living area, starter, or auxiliary battery)
EBLs distribute and protect the output circuits
The overall supply switching is via two main switches
The living area supply on / off switch and the vehicle supply on / off switch with complete isolation of all consumers from the batteries (shutdown)
Connection facility for auxiliary chargers (18 A)
Connection facility for solar charge controller (up to 25 A charging current)
D+ signal evaluation
Refrigerator supply (configurable) for absorber, compressor, or AES refrigerators
Low quiescent current consumption
Integrated overvoltage protection (OVP)
IUoU, integrated charging output with adjustable slide switch for lead acid, and AGM
Locks operating by a panel during driving

Product description

The EBL 31‑2 Electroblock Motorcaravan is a power management system designed to generate charging voltages and distribute energy across onboard batteries while protecting output circuits. Featuring dual main switches with complete isolation capability, it ensures safe and controlled operation. Compatible with auxiliary chargers and solar controllers, and equipped with IUoU charging output and overvoltage protection, it delivers reliable and efficient power management.
